SAFETY DEVICES
ORIGINAL GATE
POSITION
Obstacle
Encountered,
Acvang the
IES
Gate Response System Mode
Opening Yes Gate should reverse to closed posion; if it
encounters an infrared beam (photo eye)
input* during reversing=hard shutdown.
*or an edge sensor input, if programmed in the
same manner as the photo eye
Hard Shutdown Mode
2
Opening Yes Gate should reverse to closed posion;
if it encounters another obstacle during
reversing [via the IES (reduced speed
sensor/torque change sensor)] = hard
shutdown.
Hard Shutdown Mode
2
Closing Yes Gate should reverse to open posion and
wait for a renewed command (auto close
mer= disabled).
--
Closing Yes Gate should reverse to open posion; if it
encounters an infrared beam (photo eye)
input* during reversing = hard shutdown.
*or an edge sensor input, if programmed in the
same manner as the photo eye
Hard Shutdown Mode
2
Closing Yes Gate should reverse to open posion;
if it encounters an obstacle [via the IES
(reduced speed sensor/torque change
sensor)] during reversing = hard shutdown.
Hard Shutdown Mode
2
