ELECTRICAL CIRCUITS
1. PHOTO EYE - MANDATORY
This input allows for the photocell as a secondary safety device which monitors the path between the
gate.
Typical (example-only; model EMX-MON) photo eye connecons to the post terminaon box are:
Photo Eye Wiring - One Set
Primary Column Boom Receiver: (+)24, top terminal #6
(-)24, top terminal #10
COM, top terminal #4
NC, top terminal #15
Secondary Column Boom Transmier: (+)24, top terminal #2
(-)24, top terminal #9
Photo Eye Wiring - Two Sets
Primary Column Top Receiver: (+)24, top terminal #5
(-)24, top terminal #11
COM, top terminal #4
NC, top terminal #7
Primary Column Boom Receiver: (+)24, top terminal #6
(-)24, top terminal #10
COM, boom terminal #7
NC, top terminal #15
Secondary Column Top Transmier: (+)24, top terminal #3
(-)24, top terminal #8
Secondary Column Boom Transmier: (+)24, top terminal #2
(-)24, top terminal #9
Always refer to site-specic drawings issued for the project you are working on for actual electrical
connecons and installaon methods.
