ELECTRICAL CIRCUITS
4. STROBE WARNING DEVICE – OPTIONAL
This output allows connecons for a 24VDC strobe light to be used as a pre-warning to gate movement.
Typical (example-only; see bolded text) strobe connecons to the post terminaon box are:
STROBE LIGHT: Uses terminals (-) 14 & (+) 17
Always refer to site-specic drawings issued for the project you are working on for actual electrical
connecons and installaon methods.
