SPEEDGATE Installation and Maintenance Manual Revision 1 - MAY 2023

ELECTRICAL CIRCUITS

5. TRAFFIC LIGHT – OPTIONAL

This output allows for a red and green trac light as an addional precauonary device. This will permit

greater control over the vehicle movements in and around the SpeedGate.

Typical (example-only; see bolded text) trac light connecons to the post terminaon box are:

TRAFFIC LIGHT Uses terminals

24VDC trac light inputs: Terminal (-) #18, red light into Relay 06 terminal #2

Green light into Relay 06 terminal #4

Always refer to site-specic drawings issued for the project you are working on for actual electrical

connecons and installaon methods.

Wallace Perimeter Security SPEEDGATE - Page 91
