Description of the printer
3
2.6. Technical data
General features
Length 215 cm
Width 235 cm
Height 305 cm
Approximated weight 350 kg
Noisiness < 70 db (A)
Minimum require space for the assembly 5,5 mt x 2,5 mt x 3,6 mt
Mechanical features
Frame and cover Metal sheet and aluminium
Print bed Vacuum bed with multiple removable printing plates
Movement Rolling on anodized aluminum slide
Motors Brushless
Electrical features
Input 220/240 V - 50/60 Hz
Absorbed power Max 5000 W (1500 average)
Extruder: 600 max W
Firecap : 2000 max W
Compressed air requirements
Input >8 bars
Minimum compressor volume 50 l
8 mm inlet hose
Use features
Environment of use 15-30 °C
Warehouse 0-30 °C
Nozzle max 350 °C
Firecap max 150 °C
3D printing informations
Technology FGF (Fused Granular Fabrication)
Cilindric build area Ø 1000 x 1000 mm
Nozzle diameter Standard 3mm, Optional (2mm-5mm)
Layer resolution min 500 micron (with 2mm nozzle) - max 2500 micron (with 5mm nozzle)
Maximum speed 100 mm/s (travel: 200 mm/s)
Pellet tank capacity 20L (50L optional)
Pellet diameter From Ø 2mm up to Ø 6mm
Suitable filaments PLA, ABS (other: ASA, PP, TPE, PETG, PLASMIX)
Interface and software
Operative systems Windows, Mac, Linux
Supported slicing software Simplify3D
File formats .stl, .obj, .gcode
Interface USB pendrive, LAN, TFT touch display, Wi-Fi
Remote control Octoprint
