Installation
3
4.2. Electrical connection
ATTENTION:
The operations related to these activities must be performed by authorized and professionally
qualified personnel.
ATTENTION:
It is up to the user to protect the cable mechanically against any crushing or sources of wear
according to the type of installation made.
ATTENTION:
The printer must be powered by a 10A socket protected by a magnetothermic set at 30 mA.
NOTE:
All the data concerning the electrical characteristics of the printer can be found in the manual, see
paragraph 2.4 “Technical data”.
Before connecting the printer’s power cord to the electrical outlet, check that the system’s power consumption
and voltages are suit.
4.3. Pneumatical connection
ATTENTION:
The operations related to these activities must be performed by authorized and professionally
qualified personnel.
ATTENTION:
It is up to the user to protect the hose mechanically against any crushing or sources of wear
according to the type of installation made.
ATTENTION:
The printer must be powered by a compressor with at least 50 liters of capacity and minimum
pressure 6 bars. The hose for the connection must be 8 mm in the external diameter.
When the printer is turned on the air pressure must be provided.
