Preparing the Separations Module for Operation 9
2.2 Configuring the Separations Module
Before you can operate the Separations Module, you need to configure the Separations
Module for stand-alone or remote control and for a variety of other operating parameters.
No Interaction Mode
In this standalone mode, the Separations Module is not connected to the IEEE-488
interface bus. The Separations Module controls other non-IEEE devices in the HPLC
system using the I/O connections on the rear panel. Refer to the
Waters 2690 Separations
Module Operator’s Guide
, Section 2.7.1, I/O Signal Connections, for the procedure to
make I/O connections. Use this mode if you want to suspend communication with a
connected Millennium Chromatography Manager workstation and operate the Separations
Module and the other HPLC system components from their front panels.
To set the Separations Module to the No Interaction mode:
1. Press the
Config
screen key in the Main screen. The Configuration screen appears
(Figure 2-3
).
2. Select the
System
field, then press
Enter
to display a list of choices.
3. Select
No interaction
, then press
Enter
.
4. Press
Exit
.
System Controller Mode
In this standalone mode, the Separations Module controls up to three detector channels
on the IEEE-488 bus. This can include two UV detector channels (Waters 2487 and/or 486
Tunable Absorbance Detectors) and one RI detector channel (Waters 2410 or 410
Differential Refractometer). You can also control other HPLC modules using the I/O
connections.
To set the Separations Module to the System Controller mode:
1. Press the
Config
screen key in the Main screen. The Configuration screen appears
(Figure 2-3
).
