Wayne-Dalton 800 - Control Panel Wiring Overview

www.Wayne-Dalton.com
349981 REV2_05/17/2016
©
Copyright 2016 Wayne Dalton, a division of Overhead Door Corporation
24
Wiring Overview
HANDLE
DISCONNECT
MOTOR
CONTROLS
LCD
SCREEN
1. MAIN COMPONENT OVERVIEW, Fig. 5–C AND 5–D
Fig 5–D Control Panel Bottom/Wiring Access
Fig 5–C Control Panel Front Cover
MOTOR CABLE
5-PIN POSITION
SENSOR CABLE
12-PIN JUNCTION
BOX CABLE
MAIN POWER
(FROM DISCONNECT)
