Wayne-Dalton 800 - Table of Part Numbers

www.Wayne-Dalton.com
349981 REV2_05/17/2016
©
Copyright 2016 Wayne Dalton, a division of Overhead Door Corporation
57
Description
Built to
Order?
Item Description
Reference
Part
Number
1 Curtain Assembly, Complete Inquire Yes
2 Slat Yes
3 Endlock / Windlock
4 Complete Bottom Bar Assembly 705-0250 Yes
5 Junction Box Assembly, Bottom Bar, with fittings Yes
6 Sensing Edge, 2-Wire Failsafe Type 086896 Yes
7 Coil Cord, Spring Assist, RapidSlat 810210
8 Guide Assembly, 800 Series 709-1483/706-1542/706-1535 Yes
10
(non-standard) Hi-Use Option Wear Strip, Polyurethane
347781
Guide Weatherstrip, (not shown) 086695
11 Headplate Assembly, Non-Drive 008-4167 Yes
12
Bearing, Flange 349538
13
Headplate Assembly, Drive 008-4166
Yes
14 Spacer, Motor 810158
15 Gearmotor, Hyponic Drive 810173
Winding Eye, Handcrank (not shown) 308479
16 Barrel Assembly, 800 Series 707-0539 Yes
17 Set Collar, Locking - small ID 272322/272328
18 Keystock, 1/4" x 1/4" x 9" Long 275445
19 Limit Assembly, Absolute Encoder 308700
Absolute Encoder 810235
Chain, Limit Drive, #25 086565
Link, Connecting, #25 Chain (not shown) 080884
20 Limit Drive Sprocket 810182
BEFORE ORDERING PARTS
LOCATE YOUR ORIGINAL DOOR NUMBER
Found on the Nameplate Attached to your Bottom Bar
22
Coil Cord Junction Box, Guide Mounted
23 Crank Interlock Assembly, with cable
24 Hand Crank Assembly Yes
27 Control Panel 308695 Yes
Not Used
29 Photoeye Assembly, pair 810187
Transmitter 107322-0005
Receiver 107322-0005
30 Hood Assembly, Service Door Inquire Yes
Hood Logo, Service Doors (not shown)
OPTIONAL ACCESSORIES
Loop Module, 24VDC Inquire
Motion Detector, BEA Falcon Inquire
Remote Control, BEA Sensors Inquire
Pushbutton Station, NEMA4, O.C.S. Inquire
Radio Control
sI
nquire
Secondary Photo-eyes
Inquire
"Built to Order" parts are specific to each door manufactured,
and may be subject to manufacturer’s standard lead-times.
21 Junction Box (cables not shown) 308694
Cable Assembly, Absolute Encoder 308696
28
9 Not Used
Reference
Part
Number
Built to
Order?
Item
31
810186
810191
26 Not used
Photoeye Cable to Junction Box 308697
32 Keystock, 3/8" x 3/8" x 2-1/2" Long 273447
33 Brake Bearin
g2
71824
34 Drop Stop Device 800383
Set Collar, Locking - 1-1/2" ID
35 272322
37 Sensing Edge Safety Label Inquire
38 Safety Label
349668
36 Not Used
InquireSignaling Equipment
39 Motor Brake Release Tag
810220
308703
Illustrated Parts Breakdown (continued)
Table 9–B
Table of Part Numbers
