Wayne-Dalton 800 User Manual

www.Wayne-Dalton.com
349981 REV2_05/17/2016
©
Copyright 2016 Wayne Dalton, a division of Overhead Door Corporation
28
Fig. 5–J JUNCTION BOX WIRING
Connections for most factory wired external control functions.
Wiring Overview (continued)
CAUTION
Ensure all openings into junction box are weather tight to prevent leakage.
TO LOOP DETECTOR
OR MOTION DETECTOR
(BLACK)
TO RADIO REMOTE RECIEVER
(BLACK)
TO PHOTOEYE TRANSMITER
(GREEN)
TO PHOTOEYE RECIEVER
(CYAN)
TO SENSING EDGE
(RED)
TO HAND CRANK INTERLOCK
(ORANGE)
