www.Wayne-Dalton.com
349981 REV2_05/17/2016
©
Copyright 2016 Wayne Dalton, a division of Overhead Door Corporation
48
Section 7 (continued)
Troubleshooting
CONTROLLER
Display
Standard Inputs
Exterior Switch
Connector
UP Buon
DOWN
Buon
Wiring Guide
Reversing Edge
Terminal Block
Safety Terminal
Block: Photocell
Connecons
Control Output
Power Terminal
Block
Motor Connecon
Braking Resistor Connecon
(some models)
Output Relay
Terminal Block
Configurable Inputs
Terminal Block
RS 485 COM
Terminal Block
Motor Encoder
Connecon
Input Power
Connecons (Mains)
Brake Connecon
(oponal)
Menu/Enter Buon
Fig 7–H
