CFW500 | 5
General Information
English
Analog input
(AI1)
(*)
Digital inputs
(DI1 to DI4)
(*)
Supplies for electronics and interfaces
between power and control
RS485
PC
Power
Single-phase /
three-phase
rectifier
Internal
RFI filter
(available in
the inverters
CFW500...C...)
Motor
U/T1
V/T2
W/T3
+UD
-UD
BR
Inverter with
insulated gate bipolar
transistors and
current feedback
Power
supply
R/L1/L
S/L2/N
T/L3
= connection for DC link
(**)
= connection for brake resistor
(**)
Preload
Software WLP
SUPERDRIVE
(*)
MODBUS
Capacitor bank DC Link
Braking IGBT (available in the inverters
CFW500...DB...)
HMI
CPU
32 bits
"RISC"
EEPROM
(memory)
User’s
Plug-in
card
Interfaces
(RS232,
RS485
or USB)
Analog output
(AO1)
(*)
Power supply 24 V
Power supply 10 V
Digital output
DO1 (RL1)
Digital output
DO2 (TR)
(*)
HMI (remote)
Feedback
(**)
:
- voltage
- current
PE
PE
Memory card (MCard)
Accessory
Control
Control
Standard plug-in
= Human-machine interface
(*) The number of analog/digital inputs/outputs, as well as other resources, may vary according to the plug-in module used.
For further information, refer to the guide supplied with the accessory.
(**) Not available in frame size A.
Figure 2.1: Block diagram of CFW500 for frame sizes A, B and C
