2.3 NOMENCLATURE
Table 2.1: Nomenclature of the inverters CFW500
Product
and
Series
Identification of the Model
Brake
(*)
Protection
Rate
(*)
Conducted
Emission
Level
(*)
Safety
Functions
Hardware
Version
Special
Software
Version
Frame
Size
Rated
Current
No of
Phases
Rated
Voltage
Eg.: CFW500 A 02P6 T 4 NB 20 C2 -- --- --
Available options
CFW500
See Table 2.2 on page 9 Blank =
without
safety
functions
Blank =
standard
NB = without dynamic braking Y2 = with
safety
functions
(STO and
SS1-t, as
per IEC/EN
61800-5-2)
Sx =
special
software
DB = with dynamic braking Blank = standard
plug-in module
20 = IP20 H00 = without plug-in
N1 = cabinet Nema1 (type 1 as per UL) (protection
rate according to standard IEC IP20)
Blank = it does not meet the levels of standards
for conducted emission
C2 or C3 = as per category 2 (C2) or 3 (C3)
of IEC/EN 61800-3, with internal RFI filter
(*) The available options for each model are in Table 2.2 on page 9.
NOTE!
For models with a special software version (Sx in the smart code) and for
specific applications, refer to the application manual available for download
on www.weg.net.
