Table 2.2: Available options for each field of the nomenclature according to the rated current and voltage
of the inverter
Frame
Size
Output Rated
Current
(1)
N° of Phases
Rated
Voltage
Available Options for the Remaining Identification
Codes of the Inverters
Brake
Protection
Rate
Conducted
Emission Level
Hardware
Version
A
01P6 = 1.6 A
S = single-
phase power
supply
2 = 200... 240 V
NB
20 or N1
Blank or C2
Blank or
H00
02P6 = 2.6 A
04P3 = 4.3 A
07P0 = 7.0 A Blank or C3
B
07P3 = 7.3 A
DB C2
10P0 = 10 A
A
01P6 = 1.6 A
B = single-phase
or three-phase
power supply
NB
Blank
02P6 = 2.6 A
04P3 = 4.3 A
B
07P3 = 7.3 A
DB
10P0 = 10 A
A
07P0 = 7.0 A
T = three-phase
power supply
NB
09P6 = 9.6 A
B 16P0 = 16 A
DB
C 24P0 = 24 A
D
28P0 = 28 A
Blank or C3
33P0 = 33 A
47P0 = 47 A
E 56P0 = 56 A
A
01P0 = 1.0 A
4 = 380...480 V
NB
Blank or C2
01P6 = 1.6 A
02P6 = 2.6 A
04P3 = 4.3 A
06P1 = 6.1 A Blank or C3
B
02P6 = 2.6 A
DB
Blank or C204P3 = 4.3 A
06P5 = 6.5 A
10P0 = 10 A Blank or C3
C
14P0 = 14 A
Blank or C2
16P0 = 16 A
D
24P0 = 24 A
Blank or C3
31P0 = 31 A
E
39P0 = 39 A
49P0 = 49 A
F
77P0 = 77 A
88P0 = 88 A
0105 = 105 A
C
01P7 = 1.7 A
5 = 500...600 V Blank
03P0 = 3.0 A
04P3 = 4.3 A
07P0 = 7.0 A
10P0 = 10 A
12P0 = 12 A
(1) Informed currents in frame sizes A ... E are for HD operation and in frame size F, for ND operation.
