WEG CFW500 - Page 182

CFW500 | 177
Appendix B - Anexo B
Appendix B
Anexo B
136.2 [5.36]
206.0 [8.11]
5.8 [0.23]
6.5 [0.26]
5.3 [0.20]
16.8 [0.66]
100.0 [3.93]
6.4 [0.25]
6.2 [0.24]
B
A
A
B
210.0 [8.26]
195.0 [7.68]
9.7 [0.38]
106.1 [4.18]
100.0 [3.93]
165.1 [6.50]
96.0 [3.78]
135.2 [5.32]
92.0 [3.62]
46.7 [1.83]
16.7 [0.66]
R4.0 [0.16]
Figure B.7: Inverter dimensions in mm [in] - frame size C
Figura B.7: Dimensiones del convertidor en mm [in] - tamaño C
Figura B.7: Dimensões do inversor em mm [in] - mecânica C
