180 | CFW500
Appendix B - Anexo B
Appendix B
Anexo B
110.0 [4.33]
56.3 [2.21]
150.4 [5.92]
202.4 [7.97]
550.0 [21.65]
517.0 [20.35]
525.0 [20.67]
15.0 [0.59]
14.0 [0.55]
10.0 [0.39]
5.0 [0.20]
275.0 [10.83]
40.0 [1.57]
20 0.0 [7.87]
300.0 [11.81]
275.0 [10.83]
200.0 [7.87]
103.5 [4.07]
9.2 [0.36]
R4.5 [0.18]
12.5 [0.49]
260.0 [10.24]
9.2 [0.36]
40.0 [1.57]
DETALHE A
ESCALA 1:2
DETALHE B
ESCALA 1:2
DETALHE C
ESCALA 1:2
A
B
C
Figure B.10: Inverter dimensions in mm [in] - frame size F
Figura B.10: Dimensiones del convertidor de frecuencia en mm [in] - tamaño F
Figura B.10: Dimensões do inversor en mm [in] - tamanho F
