SSW7000 | 9-4
Technical Specifications
SSW7000B – SSW7000D – 600A
Table 9.9: Maximum time per start for the SSW7000B/D – 600A
SSW7000D - 600A
Starts per Hour ( Initial Temperature 40°C )
Current limitation 1 2 3 4 5 6 7 8 9 10
150% ( 900A ) 60s 60s 60s 60s 60s 60s 57s 49s 44s 40s
200% ( 1200A ) 60s 60s 60s 60s 53s 44s 38s 33s 29s 27s
250% ( 1500A ) 60s 60s 60s 47s 38s 32s 27s 24s 21s 19s
300% ( 1800A ) 60s 60s 47s 35s 28s 23s 20s 18s 16s 14s
350% ( 2100A ) 60s 54s 36s 27s 21s 18s 15s 13s 12s 11s
400% ( 2400A ) 60s 42s 28s 21s 17s 14s 12s 10s 9s 8s
450% ( 2700A ) 60s 32s 22s 16s 13s 11s 9s 8s 7s 6s
500% ( 3000A ) 51s 25s 17s 13s 10s 8s 7s 6s 6s 5s
550% ( 3300A ) 40s 20s 13s 10s 8s 7s 6s 5s 4s 4s
600% ( 3600A ) 31s 15s 10s 8s 6s 5s 4s 4s 3s 3s
SSW7000C – 125A
Table 9.10: Maximum time per start for the SSW7000C – 125A
SSW7000C - 125A
Starts per Hour ( Initial Temperature 40°C )
Current limitation 1 2 3 4 5 6 7 8 9 10
150% ( 188A ) 60s 60s 60s 60s 60s 60s 60s 60s 60s 60s
200% ( 250A ) 60s 60s 60s 60s 60s 60s 60s 60s 60s 60s
250% ( 313A ) 60s 60s 60s 60s 60s 60s 60s 60s 60s 60s
300% ( 375A ) 60s 60s 60s 60s 60s 60s 60s 56s 50s 45s
350% ( 438A ) 60s 60s 60s 60s 60s 55s 48s 42s 37s 33s
400% ( 500A ) 60s 60s 60s 60s 50s 42s 36s 31s 28s 25s
450% ( 563A ) 60s 60s 60s 48s 38s 32s 27s 24s 21s 19s
500% ( 625A ) 60s 60s 48s 36s 29s 24s 21s 18s 16s 14s
550% ( 688A ) 60s 54s 36s 27s 22s 18s 16s 14s 12s 11s
600% ( 750A ) 60s 40s 27s 20s 16s 13s 11s 10s 9s 8s
SSW7000C – 250A
Table 9.11: Maximum time per start for the SSW7000C – 250A
SSW7000C - 250A
Starts per Hour ( Initial Temperature 40°C )
Current limitation 1 2 3 4 5 6 7 8 9 10
150% ( 375A ) 60s 60s 60s 60s 60s 60s 60s 60s 60s 60s
200% ( 500A ) 60s 60s 60s 60s 60s 60s 60s 58s 52s 47s
250% ( 625A ) 60s 60s 60s 60s 60s 54s 46s 40s 36s 32s
300% ( 750A ) 60s 60s 60s 57s 46s 38s 33s 29s 26s 23s
350% ( 875A ) 60s 60s 56s 42s 34s 28s 24s 21s 19s 17s
400% ( 1000A ) 60s 60s 41s 31s 25s 21s 18s 16s 14s 12s
450% ( 1125A ) 60s 46s 31s 23s 18s 15s 13s 11s 10s 9s
500% ( 1250A ) 60s 33s 22s 17s 13s 11s 10s 8s 7s 7s
550% ( 1375A ) 48s 24s 16s 12s 10s 8s 7s 6s 5s 5s
600% ( 1500A ) 32s 16s 11s 8s 6s 5s 5s 4s 4s 3s
