SSW7000 | 9-3
Technical Specifications
SSW7000A – 360A
Table 9.6: Maximum time per start for the SSW7000A – 360A
SSW7000 - 360A
Starts per Hour ( Initial Temperature 40°C )
Current limitation 1 2 3 4 5 6 7 8 9 10
150% ( 540A ) 60s 60s 60s 60s 60s 60s 60s 60s 60s 60s
200% ( 720A ) 60s 60s 60s 60s 60s 60s 60s 58s 52s 46s
250% ( 900A ) 60s 60s 60s 60s 60s 57s 49s 43s 38s 34s
300% ( 1080A ) 60s 60s 60s 60s 52s 43s 37s 32s 29s 26s
350% ( 1260A ) 60s 60s 60s 51s 41s 34s 29s 25s 23s 20s
400% ( 1440A ) 60s 60s 54s 41s 32s 27s 23s 20s 18s 16s
450% ( 1620A ) 60s 60s 44s 33s 26s 22s 19s 16s 15s 13s
500% ( 1800A ) 60s 54s 36s 27s 21s 18s 15s 13s 12s 11s
550% ( 1980A ) 60s 44s 29s 22s 18s 15s 13s 11s 10s 9s
600% ( 2160A ) 60s 37s 24s 18s 15s 12s 10s 9s 8s 7s
SSW7000D – 400A
Table 9.7: Maximum time per start for the SSW7000D – 400A
SSW7000 - 400A
Starts per Hour ( Initial Temperature 40°C )
Current limitation 1 2 3 4 5 6 7 8 9 10
150% ( 600A )
60s
60s
60s
60s
60s
60s
60s
60s
60s
59s
200% ( 800A )
60s
60s
60s
60s
60s
67s
57s
50s
45s
40s
250% ( 1000A )
60s
60s
60s
60s
58s
49s
42s
36s
32s
29s
300% ( 1200A )
60s
60s
60s
55s
44s
37s
31s
27s
24s
22s
350% ( 1400A )
60s
60s
57s
43s
34s
28s
24s
21s
19s
17s
400% ( 1600A )
60s
60s
45s
34s
27s
22s
19s
17s
15s
13s
450% ( 1800A )
60s
54s
36s
27s
21s
18s
15s
13s
12s
11s
500% ( 2000A )
60s
43s
29s
22s
17s
14s
12s
11s
10s
9s
550% ( 2200A )
60s
35s
23s
17s
14s
12s
10s
9s
8s
7s
600% ( 2400A )
57s
28s
19s
14s
11s
9s
8s
7s
6s
6s
SSW7000B – SSW7000D – 500A
Table 9.8: Maximum time per start for the SSW7000B/D – 500A
SSW7000D - 500A
Starts per Hour ( Initial Temperature 40°C )
Current limitation 1 2 3 4 5 6 7 8 9 10
150% ( 750A ) 60s 60s 60s 60s 60s 60s 60s 55s 49s 44s
200% ( 1000A ) 60s 60s 60s 60s 58s 49s 42s 36s 32s 29s
250% ( 1250A ) 60s 60s 60s 51s 41s 34s 29s 26s 23s 21s
300% ( 1500A ) 60s 60s 50s 38s 30s 25s 22s 19s 17s 15s
350% ( 1750A ) 60s 57s 38s 28s 23s 19s 16s 14s 13s 11s
400% ( 2000A ) 60s 43s 29s 22s 17s 14s 12s 11s 10s 9s
450% ( 2250A ) 60s 33s 22s 17s 13s 11s 9s 8s 7s 7s
500% ( 2500A ) 51s 25s 17s 13s 10s 8s 7s 6s 6s 5s
550% ( 2750A ) 39s 19s 13s 10s 8s 6s 6s 5s 4s 4s
600% ( 3000A ) 29s 14s 10s 7s 6s 5s 4s 4s 3s 3s
