SSW7000 | 9-2
Technical Specifications
Table 9.3: Maximum motor power driven by SSW7000C
Model
Voltage
2300V
4160V
6900V*
cv
kW
cv
kW
cv
kW
125 A 500 400 1000 730 1650 1220
250 A 1100 810 2100 1550 3250 2400
360 A 1600 1180 3000 2200 4700 3500
For bigger motor power, please contact WEG.
The SSW7000 standard is designed to withstand a 4,5xIn overload duty for 30s, the SSW7000C standard is
designed to withstand a 4xIn overload duty for 20s.
In order to select the SSW7000 model according to the desired overload duty, see table 9.4 to table 9.12,
which inform the maximum motor starting time for different current levels and different quantities of starts per
hour.
NOTE!
For different overload duties, it is important to take into account the correct sizing of the medium-
voltage fuses.
SSW7000A – SSW7000D – 180A
Table 9.4: Maximum time per start for the SSW7000A/D – 180A
SSW7000 - 180A
Starts per Hour ( Initial Temperature 40°C )
Current limitation 1 2 3 4 5 6 7 8 9 10
150% ( 270A ) 60s 60s 60s 60s 60s 60s 60s 60s 60s 60s
200% ( 360A ) 60s 60s 60s 60s 60s 60s 60s 60s 60s 60s
250% ( 450A ) 60s 60s 60s 60s 60s 60s 57s 50s 44s 40s
300% ( 540A ) 60s 60s 60s 60s 54s 45s 38s 34s 30s 27s
350% ( 630A ) 60s 60s 60s 45s 36s 30s 26s 23s 20s 18s
400% ( 720A ) 60s 59s 39s 30s 24s 20s 17s 15s 13s 12s
450% ( 810A ) 60s 36s 24s 18s 15s 12s 10s 9s 8s 7s
500% ( 900A ) 39s 19s 13s 10s 8s 6s 6s 5s 4s 4s
550% ( 990A ) 12s 6s 4s 3s 3s 3s 2s 2s 2s 2s
600% ( 1080A ) 2s 2s 2s 2s 2s 1s 1s 1s 1s 1s
SSW7000A – SSW7000D – 300A
Table 9.5: Maximum time per start for the SSW7000A/D – 300A
SSW7000 - 300A
Starts per Hour ( Initial Temperature 40°C )
Current limitation 1 2 3 4 5 6 7 8 9 10
150% ( 450A ) 60s 60s 60s 60s 60s 60s 60s 60s 60s 60s
200% ( 600A ) 60s 60s 60s 60s 60s 60s 60s 55s 49s 44s
250% ( 750A ) 60s 60s 60s 60s 59s 49s 42s 37s 33s 29s
300% ( 900A ) 60s 60s 60s 51s 40s 34s 29s 25s 22s 20s
350% ( 1050A ) 60s 60s 47s 35s 28s 23s 20s 18s 16s 14s
400% ( 1200A ) 60s 49s 32s 24s 19s 16s 14s 12s 11s 10s
450% ( 1350A ) 60s 33s 22s 16s 13s 11s 9s 8s 7s 7s
500% ( 1500A ) 41s 21s 14s 10s 8s 7s 6s 5s 5s 4s
550% ( 1650A ) 23s 11s 8s 6s 5s 4s 3s 3s 3s 3s
600% ( 1800A ) 8s 4s 3s 3s 2s 2s 2s 2s 2s 2s
