Product description
Wieland Electric GmbH | BA000966 | 07/2016 (Rev. C)
26
COMPACT module SP-COP2-ENI
888369803
Description
888371339
COMPACT module SP-COP2-ENI has the same functionality and has the same connections
and the same displays as the SP-COP2-EN [ch. 3.5, p. 21] .
In addition, this module has the following gateway functionality on-board:
• Modbus/TCP interface
• PROFINET IO interface
• EtherNet/IP interface
Module versions
In addition to the basic version there is the SP-COP2-ENI-
P
compact module.
This has additional press control functions.
Display elements, error codes, and terminal description
888372363
The displays of the MS and CV LEDs as well as the terminal assignment of the USB and Ether-
net interface are identical to those for the SP-COP2-EN controller module.
Further information:
Display elements, interfaces, and terminal description [ch. 3.5.2, p. 21]
COMPACT SP-COP-CARD1 removable storage
888373387
Description
888374923
The system configuration of the entire samosPRO system is stored in the SP-COP-CARD1 pro-
gram removable storage. This has the advantage that the samosPRO system does not have to
be reconfigured when modules are replaced.
The COMPACT SP-COP-CARD1 removable storage is an SD card that is produced and for-
matted specially for use in COMPACT modules.
NOTICE
• The data stored in the SP-COP-CARD1 program removable storage will be retained even
if the supply voltage is interrupted.
• When replacing
a module, make sure that the program removable storage is inserted into
the appropriate COMPACT module. Mark all of the connection lines and plug connectors
on the samosPRO system clearly to prevent mixups.
• Commonly available SD cards cannot be used/inserted in samosPRO and COMPACT mo-
dules.
