SP-DIO input/output expansion module
1126553227
Table 50: SP-DIO data sheet
SP-DIO
Protection class
III (EN 61140)
Protection type Terminals: IP 20 (EN 60529)
Housing: IP 40 (EN 60529)
Ambient temperature during opera-
tion
-25 … +55 °C
Storage temperature
-40 … +70 °C
Humidity
10 ... 95%, non-condensing
Fatigue strength
5 Hz… 150 Hz, 3.5 mm peak 1 g (EN 60068 2 6)
Shock resistance
30 g, 11 ms (EN 60068-2-27)
Electromagnetic compatibility EN 61000 6 2, Class A (EN 55011) Emission
EN 61000-6-4 Immission
System connection
Terminal with screw or spring-loaded connection
Power consumption via SBUS+
max. 0.5 W
Data interface
Internal bus (SBUS+)
Dimensions (W × H × L)
22.5 × 96.5 × 120.8 mm
Weight
150 g (± 5%)
Terminal and connection data
Screw terminal
Spring-loaded terminal
Single-wire or fine-strand 1 x 0.2–2.5 mm
2
2 x 0.2-1.0 mm
2
2 x 0.2-1.5 mm
2
Fine-strand with ferrules as per EN
46228
1 × 0.25–2.5 mm² or
2 × 0.25–1.0 mm²
1 × 0.25–1.5 mm² (trape-
zoid crimping)
AWG
26-14
24-16
Maximum tightening torque
0.5-0.6 Nm (4–5 lbf-in)
—
Stripping length
Max. 7 mm
Power supply (A1, A2)
Supply voltage
24 V DC (16.8 to 30 V DC)
Type of supply voltage
PELV or SELV
Power consumption
max. 120 W (depending on load)
Switch-on time
max. 18 s
Short-circuit protective device
4 A gG (tripping characteristic B or C)
Input circuit (I1–I4 & IY5-IY8)
Number of inputs
4 to max. 8 (depending on configuration)
Input voltage HIGH
13 V DC… 30 V DC
Input voltage LOW
–3 V DC … +5 V DC
Input current HIGH 2 mA … 3.5 mA
Input current LOW
0 mA… 1.0 mA
