Technical data
Wieland Electric GmbH | BA000966 | 07/2016 (Rev. C)
79
SP-SDIO input/output expansion module
888564875
Table 48: SP-SDIO data sheet
SP-SDIO
T
M
(usage time)
20 years (EN ISO 13849)
1
Protection class
III (EN 61140)
Protection type Terminals: IP 20 (EN 60529)
Housing: IP 40 (EN 60529)
Ambient temperature during opera-
tion
-25 … +65 °C
Storage temperature
-25 … +70 °C
Humidity
10 to 95 %, non-condensing
Fatigue strength
5 to 500 Hz/5 g (EN 60068-2-6)
Shock resistance
• Continuous shock
• Brief shock
10 g, 16 ms (EN 60068-2-29)
30 g, 11 ms (EN 60068-2-27)
Electromagnetic compatibility
Class A (EN 61000-6-2, EN 55011)
System connection
Terminal with screw or spring-loaded connection
Power consumption via SBUS+
without currents at X1, X2
max. 1.1 W
Data interface
Internal bus (SBUS+)
Dimensions (W × H × L)
22.5 × 96.5 × 120.8 mm
Weight 164 g (± 5%)
Terminal and connection data
Screw terminal
Spring-loaded terminal
Single-wire or fine-strand 1 x 0.2-2.5 mm
2
2 x 0.2-1.0 mm
2
2 x 0.2-1.5 mm
2
Fine-strand with ferrules
as per EN 46228
1 × 0.25–2.5 mm² or 2 ×
0.25–1.0 mm²
1 × 0.25–1.5 mm²2 (tra-
pezoid crimping)
AWG
26-14
24-16
Maximum tightening torque
0.5-0.6 Nm (4–5 lbf-in)
—
Stripping length
Max. 7 mm
Output supply (A1, A2)
Supply voltage
24 V DC (16.8 to 30 V DC)
Type of supply voltage PELV or SELV
The current for the powerpack must be limited to a
maximum of 4 A – either by the powerpack itself or
by a fuse.
Power consumption
1W
Switch-on time
Max. 18 s
Short-circuit protective device
4 A gG (with tripping characteristic B or C)
