Transponder switches
888483339
Table 31: Transponder connection
Electrical connection: Example from samosPLAN5+
With OSSD OSSD1 at I1
OSSD2 at I2
Table 32: Functions with transponders
Function
Info
Series connec-
tion/cascading
Possible, depending on type used
NOTICE
You can find additional information in the operating instructions for the respective transpon-
der switch.
4
.2.3
