Technical data
Wieland Electric GmbH | BA000966 | 07/2016 (Rev. C)
82
SP-SDI input/output expansion module
888565899
Table 49: SP-SDI data sheet
SP-SDI
Safety Integrity Level
1
SIL3 (IEC 61508)
Category
Category 4 (EN ISO 13849-1)
Performance Level
1
PL e (EN ISO 13849-1)
PFHd (average probability of a ha-
zardous-causing failure per hour)
5.68 · 10–
9
T
M
(usage time)
20 years (EN ISO 13849)
Protection class
III (EN 61140)
Protection type Terminals: IP 20 (EN 60529)
Housing: IP 40 (EN 60529)
Ambient temperature during opera-
tion
-25 to +55 °C
Storage temperature
-25 to +70 °C
Humidity
10 to 95%, non-condensing
Climatic conditions
55°C, 95% relative humidity (EN 61131-2)
Fatigue strength as per EN 61131-2
5 to 500 Hz
Fatigue strength as per
EN 60068-2-6
10 to 500 Hz/5 g
Shock resistance
• Continuous shock
• Brief shock
10 g, 16 ms (EN 60068-2-29)
30 g, 11 ms (EN 60068-2-27)
Electromagnetic compatibility
Class A (EN 61000-6-2, EN 55011)
System connection
Double-level spring-loaded terminals
Power consumption via SBUS+
without currents at X1 to X8
Max. 1.4 W
Terminal and connection data
Screw terminal
Spring-loaded terminal
Single-wire or fine-strand 1 x 0.2-2.5 mm
2
2 x 0.2-1.0 mm
2
2 x 0.2-1.5 mm
2
Fine-strand with ferrules
as per EN 46228
1 × 0.25–2.5 mm² or 2 ×
0.25–1.0 mm²
1 × 0.25–1.5 mm² (trape-
zoid crimping)
AWG
26-14
24-16
Maximum tightening torque
0.5-0.6 Nm (4–5 lbf-in)
—
Stripping length
Max. 7 mm
Dimensions (W × H × L)
22.5 × 96.5 × 120.8 mm
Weight
139 g (± 5%)
