Wieland SP-SDIO - Module Data Sheets

Technical data
Wieland Electric GmbH | BA000966 | 07/2016 (Rev. C)
75
Data sheet
888562315
SP-COP1 and SP-COP2-ENx modules
888563851
Table 47: SP-COP1 and SP-COP2-ENx data sheet
SP-COP1 / SP-COP-xxx
Safety Integrity Level
SIL3 (IEC 61508)
SIL claim limit
1
SILCL3 (EN 62061)
Category
Category 4 (EN ISO 13849-1)
Performance Level
1
PL e (EN ISO 13849-1)
PFHd (average probability of a ha-
zardous-causing failure per hour)
T
M
(usage time)
20 years (EN ISO 13849)
Protection class
III (EN 61140)
Protection type
IP 20 (EN 60529)
Ambient temperature during opera-
tion
-25 to +65°C
Storage temperature
-25 to +70 °C
Humidity
10 to 95%, non-condensing
Fatigue strength
5 … 150 Hz (EN 60068-2-6)
Shock resistance
• Continuous shock
• Brief shock
10 g, 16 ms (EN 60068-2-29)
30 g, 11 ms (EN 60068-2-27)
Electromagnetic compatibility
Class A (EN 61000-6-2, EN 55011)
Data interface
Internal bus (SBUS+)
Configuration interface 1
USB mini
Configuration interface 2 RJ 45
Dimensions (W × H × L)
45 × 96 × 115 mm
Weight
290 g (± 5%)
Terminal and connection data
Screw terminal
Spring-loaded terminal
Single-wire or fine-strand 1 x 0.2–2.5 mm
2
2 x 0.2–1.0 mm
2
2 x 0.2–1.5 mm
2
Fine-strand with ferrules
as per EN 46228
1 × 0.25–2.5 mm
2
or 2 ×
0.25–1.0 mm
2
1 × 0.25–1.5 mm
2
(trape-
zoid crimping)
AWG
26-14
24-16
Maximum tightening torque
0.5–0.6 Nm
—
Stripping length
Max. 7 mm
