samosPRO COMPACT (SP-COPx with I/O expansion SP-SDI and/or SP-SDIO)
888560779
Table 46: Safety technology reference values for samosPRO COMPACT (with I/O expansion)
Characteristic values
Configuration of safety outputs
Output groups:
SP-COPx:
Q1/Q2, Q3/Q4, IQ1/IQ2, IQ3/IQ4
SP-SDIO:
Q1/Q2/Q3/Q4
Safety Integ-
rity Level
(IEC 61508)
1
Category
(EN ISO
13849-1)
Performance
level (EN ISO
13849-1)
1
PFHd
2
Single-
channel
or two-
channel
input
Two-channel outputs (with or without
test pulses)
SIL3 4 PL e 4.3 · 10
–9
Single-
channel
output Q
n
for an out-
put group
Test pulses at all outputs
of an output group acti-
vated
SIL3 4 PL e 4.3 · 10
–9
Test pulses at one output
of the output group acti-
vated and test pulses at
the other output of the
output group deacti-
vated.
The value indicated refers
to the output with acti-
vated test pulses.
SIL3 3 PL e 4.3 · 10
–9
Output test pulses deac-
tivated
SIL2 3 PL d 1.7 · 10
-8
1
For detailed information regarding the safety configuration of your machine/system, please
contact the Wieland Electric branch in charge of your area.
2
Average probability of a hazard-causing failure per hour
12.2.2
