Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
© Woodward Page 117/179
Starting Without Closing GCB
Parameter 212
Start without CB
cool down ON
Only if terminal 6 has been con-
figured to "start without CB".
Perform engine cool down if starting without CB has been selected ON/OFF
ON ................ After removing the start request (terminal 6 has been de-energized),
an engine cool down is performed for the time configured in Para-
m
eter 270.
OFF .............. After removing the start request (terminal 6 has been de-energized),
the engine is stopped immediately without an engine cool down.
Alarm Classes Enabled During Sprinkler Coasting
Parameter 213
Sprinkler shutd.
F1 active ON
Only if terminal 6 has been
configured to
"Sprinkler operation".
Sprinkler alarm classes only active if terminal 6 is energized ON/OFF
ON ................ If terminal 6 is configured as "Sprinkler operation", the alarm classes
will be enabled after the sprinkler demand has been terminated and
the coasting has expired (terminal 6 is energized and sprinkler coast-
ing 10 minutes).
OFF .............. If terminal 6 is configured as "Sprinkler operation", the alarm classes
will be enabled after the sprinkler demand has been terminated (ter-
minal 6 is energized).
Sprinkler (Critical) Operation
NOTE
Terminal 6 must be configured for the "Sprinkler operation" functionality.
ATTENTION
The sprinkler operation function is a negative logic function. Terminal 6 must remain energized to pre-
vent a Sprinkler (critical) operation from being performed. De-energizing terminal 6 will initiate a
Sprinkler (critical) operation.
Sprinkler "ON": If terminal 6 de-energizes, the Sprinkler (critical) operation ON command is initiated. The
message "Sprinkler operation" is shown on the display. Up to 6 attempts are made to start the engine if it is not
already in operation. All fault conditions or discrete inputs, which result in shutdown, become messages with the
exceptions of terminals 34 or 61 and overspeed. The alarm input for terminal 34 will still shut the engine down.
Terminal 61 is used for this if terminal 34 is not present on the control. It is recommended that EMERGEN-
CY STOP be assigned to one of these terminals.
