Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
© Woodward Page 67/179
Interface
NOTE
For remote acknowledgement of alarms, a remote stop while in idle mode must be performed. If the
control is in an isolated operation, an acknowledgement combined with a remote start must be per-
formed.
Parameter 107
Control via
COM X1X5 ON
Control via interface COM X1-X5 ON/OFF
ON ................ The remote control interface via the CAN bus (X1X5 terminals) is
enabled. This parameter requires that "Direct configuration" (Para-
m
eter 3) be configured "OFF", the AUTOMATIC operation mode
must be enabled, and the discrete input "Automatic 2" (terminal 5)
has been energized
.
When remote control of a unit has been enabled, it is possible to start
and stop the engine, acknowledge alarms, and change the real power
and power factor set points via CAN bus communication. The meas-
ured values and states of the controller may be monitored as well.
OFF .............. The remote control interface via the CAN bus (X1X5 terminals) is
disabled. The generator real power is controlled in the accordance
with how "Automatic 2" (Parameter 36) and the "Power factor con-
t
rol set point" (Parameter 68) are configured when the "Automatic 2"
di
screte input is energized.
Parameter 108
Supervision
COMX1X5 ON
if COMX1X5 = ON only
Remote monitoring of the interface ON/OFF
ON ................ Monitoring of the remote control interface is enabled. The controller
monitors to ensure the control signal (CAN ID 503) is received every
90 seconds. If the control signal is not received every 90 seconds, a
class 1 (warning) alarm is issued.
OFF .............. Monitoring of the interface is disabled.
Parameter 109
Ackn. F2,F3 via
COM interf ON
if COMX1X5 = ON only
Remote acknowledgment of F2/F3 alarms via the interface ON/OFF
ON ................ Acknowledgement of class F2/F3 alarms via the remote control inter-
face is enabled.
OFF .............. Acknowledgement of class F2/F3 alarms via the remote control inter-
face is disabled. Acknowledgment of alarms is performed by energiz-
ing the "Acknowledgment" discrete input (terminal 6) or by pressing
the "RESET" push button.
NOTE
For the description of the second interface (Option SB03 and Option SC10) refer to the following ma-
nuals:
• Option SB03 = manual 37200
• Option SC10 = manual 37382
