Manual 37365A GCP-30 Series Packages - Genset Control
© Woodward Page 119/179
Analog Inputs (XPD, XPQ)
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
NOTE
The parameters for this control are grouped together in blocks to permit navigation through the large
number of configuration screens more rapidly. Selecting "YES" or "NO" has no effect whether or not
control or monitoring is carried out for the parameters located in that block. Selecting "YES" or "NO"
only determines if the individual parameters may be accessed and changed or are bypassed.
Parameter 214
Configure
analg.inp. YES
Configuration of analog inputs YES/NO
The analog inputs functionality and logic are configured in this block of parame-
ters. This parameter has the following effects:
YES .............. The parameters in this block are displayed and can either be viewed
("Select" button), or modifications can be made to the parameters
("Cursor→", "Digit↑" or "Select" buttons).
NO ................ The parameters in this block are not displayed, cannot be modified,
and are skipped.
Setting The Analog Inputs
The analog inputs [T1] to [T7] are only available in the XPD and XPQ packages. The analog input types and
specification are as follows:
• Scaleable analog input 0/4 to 20 mA (page 120)
•
Pt100 input (page 119)
•
VDO input (temperature, page 122 or pressure, page 123)
Analog input 1 2 3 4 5 6 7
Assignment 0/4 to 20 mA Pt100 VDO #1 VDO #2
Terminal 93/94/95 96/97/98 99/100/101 101/102/103 104/105/106 107/108/109 110/111/112
VDO #1 = 0 to 180 Ohm, VDO #2 = 0 to 380 Ohm
NOTE
If you want to visualize the analog inputs via the PC program LeoPC1 (Firmware Version 4.0.xxx or
higher) the following must occur:
1. Establish a connection between LeoPC1 and the GCP.
2. Select in the menu "Devices" the topic "Refresh Configuration".
3. Restart LeoPC1 according to the requests.
