Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
© Woodward Page 165/179
Appendix D.
List of Parameters
Unit number P/N _____________________________ Rev _______________________________
Version GCP-30 _______________________________________________________________
Project _____________________________________________________________________
Serial number S/N _______________ Date ______________________________
Access
Parameter Setting range Default value Customer setting
Software version
- V x.xxxx - -
Enter code
0 to 9.999 XXXX
Direct para.
YES/NO NO  Y  N  Y  N
Generator number
1 to 14 1
Language
first/second first  f  s  f  s
Check event list
YES/NO NO  Y  N  Y  N
GENERATOR AND MAINS ENVIRONMENT CONFIGURATION
Configure measuring
YES/NO NO  Y  N  Y  N
Generator freq. f set
40.0 to 70.0 Hz 50.0 Hz
Gen.volt.transf. secondary
50 to 125/50 to 480 V 400 V
Gen.volt.transf. primary
0.05 to 65.0 kV 0.4 kV
Bus.volt.transf. secondary
50 to 125/50 to 480 V 400 V
Bus.volt.transf. primary
0.05 to 65.0 kV 0.4 kV
mains volt.trans. secondary
50 to 125/50 to 480 V 400 V
mains volt.trans primary
0.05 to 65.0 kV 0.4 kV
Gen.voltage U set
50 to 125/50 to 530 V 100/400 V
Rated voltage in system
50 to 125/50 to 480 V 100/400 V
Volt.meas./mon.
Ph-neut/Ph-Ph [4/3]
Ph-Ph/Ph-Ph [3/3]
Ph-neut/Ph-neut [4/4]
Ph-neut/Ph-Ph  4/3
 3/3
 4/4
 4/3
 3/3
 4/4
Current transf. generator
10 to 7,000/{X} A 500/{X} A
Power measuring gen.
singlephase [1]
threephase [3]
threephase  1
 3
 1
 3
Rated power generator
5 to 9,999 kW 200 kW
Rated current generator
10 to 7,000 A 300 A
Current transf. mains
5 to 7,000/{X} A 500 {X} A
XPD, XPQ
Analog in Pmains
OFF/T{x} OFF
XPD, XPQ
Analog in Pmains
0 to 20 mA
4 to 20 mA
4 to 20 mA  0-20 mA
 4-20 mA
 0-20 mA
 4-20 mA
XPD, XPQ
Analog in Pmains 0%
0 to +/-9,990/0 to +/-6,900 kW -200 kW
XPD, XPQ
Analog in Pmains 100%
0 to +/-9,990/0 to +/-6,900 kW 200 kW
GCP-31
XPD, XPQ
LS 4 mode
ON/OFF OFF  on  off  on  off
GCP-31
XPD, XPQ
Rated power in system
0 to 16,000 kW 1,600 kW
Temperature in
Celsius [°C]
Fahrenheit [°F]
Celsius [°C]  °C
 °F
 °C
 °F
Pressure in
bar
psi
bar  bar
 psi
 bar
 psi
Define level 1 code
0 to 9999 0001
Define level 2 code
0 to 9999 0002
