Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
© Woodward Page 133/179
Start/Stop Sequence 'Diesel Engine'
NOTE
The configured number of start attempts (Parameter 264) will be performed.
t/s
t
Sta VG
t t
Ein SPZ
t
1500 1/min
ZD
MV
t
0,5 s
VG
t t
Ein
0,5 s
N
t
Speed governor
Pre-glow
Starter
Start relay
Start request
Engine monitoring
activated
Delayed engine
monitoring 00s
Start Stop
Approach idle
gas position
Start attempt
unsuccessful
Start attempt
successful
Ignition speed reached
Start frequency
f-contr. + time
Figure 3-15: Start-stop sequence: Diesel engine
The signs and indices mean:
t
Sta
........... Approach idle fuel position [s]
t
VG
........... Pre-glow time [s]
t
Ein
........... Crank time [s]
t
SPZ
.......... Time between two start attempts [s]
t
MV
.......... Delayed engine monitoring [s]
t
N
............. Engine cool down time [s]
