Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
Page 74/179 © Woodward
Breaker Logic
NOTE
Using the discrete input "Change breaker logic via terminal 64" (Parameter 207), the breaker logic may
be switched between two different breaker logics (description on page 113). The primary breaker logic
is configured in Parameter 111. If Parameter 206 is configured as "ON", the discrete input terminal 64 is
used as a control input. When terminal 64 is energized, the secondary
breaker logic configured in Para-
meter 207 is en
abled. When terminal 64 is de-energized, the primary breaker logic configured in Para-
meter 111 is en
abled. Therefore it is possible during operation to change between the breaker logic
"PARALLEL" (automatic synchronizing) and "EXTERNAL" (manual synchronizing) with the flip of a
switch.
Parameter 111
Breaker logic:
----------------
only accessible via LeoPC1
Breaker logic see below
The GCP may be configured to utilized two different breaker logics. Depending on
the unit, there are up to five breaker logic modes to select from. The available
breaker logic modes are:
GCP-31 GCP-32
EXTERNAL EXTERNAL
PARALLEL PARALLEL
--- OPEN TRANSIT.
--- CLOSED TRANSIT.
--- INTERCHANGE
A detailed explanation for each mode may be found in the following text.
