Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
Page 68/179 © Woodward
Breaker
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
NOTE
The parameters for this control are grouped together in blocks to permit navigation through the large
number of configuration screens more rapidly. Selecting "YES" or "NO" has no effect whether or not
control or monitoring is carried out for the parameters located in that block. Selecting "YES" or "NO"
only determines if the individual parameters may be accessed and changed or are bypassed.
Parameter 110
Configure
breaker YES
Configuration of the breakers YES/NO
The breaker control functions are configured in this block of parameters. This pa-
rameter has the following effects:
YES .............. The parameters in this block are displayed and can either be viewed
("Select" button), or modifications can be made to the parameters
("Cursor→", "Digit↑" or "Select" buttons).
NO………… The parameters in this block are not displayed, cannot be modified,
and are skipped.
Functional Description
Permissible Limits
If the generator or mains monitoring for over-/undervoltage (Parameter 174) or over-/underfrequency (Para-
m
eter 168) is disabled, the CB logic (Parameter 111), the control uses internal
ly defined default limits for genera-
tor and mains monitoring.
The internally defined default limits always are used to monitor the busbar.
Voltage Frequency
Generator V
Gen
: 75 to 115 % V
Rate
d
f
Gen
: 80 to 110 % f
Rate
d
Busbar V
Busba
r
: 85 to 112.5 % V
Rate
d
f
Busba
r
: 90 to 110 % f
Rate
d
Mains V
Mains
: 85 to 112.5 % V
Rate
d
f
Mains
: 90 to 110 % f
Rate
d
Table 3-4: Limit values, permissible limits
The permissible limits refer to the respective rated values in the system, such as the system rated voltage (Para-
meter 17) and the system rated frequency (Parameter 9).
