Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
Page 110/179 © Woodward
Discrete Inputs
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
NOTE
The parameters for this control are grouped together in blocks to permit navigation through the large
number of configuration screens more rapidly. Selecting "YES" or "NO" has no effect whether or not
control or monitoring is carried out for the parameters located in that block. Selecting "YES" or "NO"
only determines if the individual parameters may be accessed and changed or are bypassed.
Parameter 198
Configure
dig.inputs YES
Configuration of discrete inputs YES/NO
The discrete inputs functionality and logic are configured in this block of parame-
ters. This parameter has the following effects:
YES .............. The parameters in this block are displayed and can either be viewed
("Select" button), or modifications can be made to the parameters
("Cursor→", "Digit↑" or "Select" buttons).
NO ................ The parameters in this block are not displayed, cannot be modified,
and are skipped.
NOTE
The discrete inputs can be used as alarm inputs or control inputs. If they were configured as alarm in-
puts (Parameter 204 to Parameter 210 are configured to "OFF") the parameters in "Alarm Inputs"
(p
age 111) are valid. If they have been configured as control inputs (Parameter 204 to Parameter 210
are co
nfigured to "ON") the parameters in "Control Inputs" (page 113) are valid.
