Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
Page 114/179 © Woodward
Change breaker logic via terminal 64
Parameter 206
Breaker logic
by Term64 ON
only accessible via LeoPC1
Breaker logic via terminal 64 ON/OFF
OFF .............. This terminal is used as an alarm input.
ON ................ This terminal is used as control input.
• Energized When this terminal is energized, the breaker logic of
Parameter 207 is used.
• De-en
ergized When this terminal is de-energized, the breaker logic
of Parameter 111 is used.
Parameter 207
Breaker logic:
----------------
Visible only if breaker logic via
terminal 64 is configured to
"ON".
Breaker logic via terminal 64 see page 74
Selection of the breaker logic that is to be used when terminal 64 is energized. This
parameter is only displayed if Parameter 206 has been configured to ON (for the
descri
ption of the breaker logic refer to the "Breaker logic" section on page 74).
Enable 'Close GCB without engine delay' via terminal 67
Parameter 208
Close GCB asap
by Ter.67 ON
Close GCB before the delayed engine monitoring expires via terminal 67 ON/OFF
OFF .............. This terminal is used as an alarm input.
ON ................ This terminal is used as control input.
• Energized When this terminal is energized, the GCB closes be-
fore the delayed engine monitoring expires.
• De-energized When this terminal is de-energized, the GCB closes
after the delayed engine monitoring has expired.
Enable 'Emergency OFF' via terminal 68
Parameter 209
Emergency OFF
by Ter.68 OFF
only version 4.3010 or later
only accessible via LeoPC1
Prevent an emergency power operation via terminal 68 ON/OFF
OFF .............. This terminal is used as an alarm input.
ON ................ This terminal is used as control input.
• Energized When this terminal is energized, an emergency power
operation is prevented or terminated. The unit oper-
ates as if Parameter 137 "Emergency power" is dis-
abled.
• De-en
ergized When this terminal is de-energized, an emergency
power operation may be performed. The unit oper-
ates in the manner prescribed by Parameter 137
"Em
ergency power".
