Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
Page 166/179 © Woodward
Access
Parameter Setting range Default value Customer setting
CONTROLLER CONFIGURATION
Configure controller
YES/NO NO  Y  N  Y  N
Power controller Pset1
C/I/E 0 to 9,999 kW C 50 kW
Power controller Pset2
C/I/E 0 to 9,999 kW C 80 kW
BPQ, XPQ
Initial state Frequency
0 to 100 % 50 %
Freq.controller
ON/OFF ON  on  off  on  off
f-contr. active at:
0.0 to 70.0 Hz 40.0 Hz
Delay time for f-contr.
0 to 999 s 5 s
Freq.controller ramp
1 to 50 Hz/s 10 Hz/s
BPQ, XPQ
F/P contr.type
Three-step
Analog
PWM
Analog  Three-st.
 Analog
 PWM
 Three-st.
 Analog
 PWM
Freq.controller deadband
0.02 to 1.00 Hz 0.03 Hz
Freq.controller time pulse>
10 to 250 ms 80 ms
Freq.controller gain Kp
0.1 to 99.9 20.0
BPQ, XPQ
F/P contr.output
Refer to Parameter 46 +/-10 V
BPQ, XPQ
Level PWM
3.0 to 10.0 V 3.0 V
BPQ, XPQ
Stepper sign.frq (min.)
0 to 100 % 0 %
BPQ, XPQ
Stepper sign.frq (max.)
0 to 100 % 100 %
BPQ, XPQ
Freq.controller gain Kpr
1 to 240 20
BPQ, XPQ
Freq.controller reset Tn
0.0 to 60.0 s 1.0 s
BPQ, XPQ
Freq.controller derivat.Tv
0.00 to 6.00 s 0.00 s
BPQ, XPQ
Starting point voltage
0 to 100 % 50 %
Volt.controller
ON/OFF ON  on  off  on  off
Initial state U control.
12.0 to 100.0 % 75 %
Delayed. Start U contr.
0 to 999 s 3 s
BPQ, XPQ
V/Q contr.type
Three-step
Analog
Analog  Three-st.
 Analog
 Three-st.
 Analog
Volt.controller dead band
0.1 to 15.0 % 0.9 %
Volt.controller time pulse>
20 to 250 ms 80 ms
Volt.controller gain Kp
0.1 to 99.9 20.0
BPQ, XPQ
V/Q contr.output
Refer to Parameter 61 +/-10 V
BPQ, XPQ
Stepper sign.vol (min.)
0 to 100 % 0 %
BPQ, XPQ
Stepper sign.vol (max.)
0 to 100 % 100 %
BPQ, XPQ
Volt.controller gain Kpr
1 to 240 20
BPQ, XPQ
Volt.controller reset Tn
0.0 to 60.0 s 1.0 s
BPQ, XPQ
Volt.controller derivat.Tv
0.00 to 6.00 s 0.00 s
