Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
© Woodward Page 123/179
VDO Input 'Pressure' (Analog Input [T6])
NOTE
The default threshold values are configured in "bar". If the engineering unit "psi" is configured (Para-
meter 144), the display of the measured values as well as the transmission via the interface appears in
"psi".
VDO inputs for pressure may be monitored here. The analog input is displayed with its description. Two thre-
shold levels can be monitored. The first level initiates a class F1 alarm, the second level initiates a class F3 alarm.
Parameter 230
Analog input 6
VDO ON
VDO input, pressure; enable/disable ON/OFF
ON ................ The value of this input appears in the display and monitoring is
enabled. The subsequent parameters of this function are displayed.
OFF .............. The value of this input does not appears in the display and monitor-
ing is disabled. The subsequent parameters of this function are not
displayed.
NOTE
If the unit is equipped with a second communication interface (Option SB03 and Option SC10), the
alarm texts can only be configured via LeoPC1.
Parameter 231
Name and unit
----------------
VDO input, pressure; description User defined text
The description of the analog input may be programmed using this parameter. A
maximum of four zeros may be used as placeholders for the numerical measured
values. Characters may divide the placeholders (i.e. a comma). The measured val-
ues subsequently appear wherever the zeros are placed. The measured value will
always be displayed and transmitted via the interface in bar [× 0.1] or psi [× 0.1].
Parameter 232
Analog input 6
VDO 0-00bar
VDO input, pressure; measuring range 0 to 5 / 0 to 10 bar
The measuring range of the analog input can be selected.
0 to 5 bar ..... Measuring range 0 to 180 Ohm
0 to 10 bar ... Measuring range 0 to 180 Ohm
Parameter 233
Limit warning
value 00.0bar
VDO input, pressure; limit value for class F1 alarm 0.0 to 10.0 bar
If the measured value exceeds or falls below this configured threshold value (de-
pendent upon Parameter 236) for at least the delay time (Parameter 235), the fol-
lo
wing alarm class is initiated.
Issuing of F1 class alarm
Parameter 234
Limit shutdown
value 00.0bar
VDO input, pressure; limit value for class F3 alarm 0.0 to 10.0 bar
If the measured value exceeds or falls below this configured threshold value (de-
pendent upon Parameter 236) for at least the delay time (Parameter 235), the fol-
lo
wing alarm class is initiated.
Issuing of F3 class alarm
