Parameter 141
Gen.power monit.
resp.val1 0000kW
Power monitoring threshold value, level 1 0 to 9,999 kW
If this threshold value has been exceeded for at least the delay time (Para-
meter 143), the relay assigned relay manager function 56 energizes.
Parameter 142
Gen.power monit.
hyst.lv1 000kW
Power monitoring hysteresis, level 1 0 to 999 kW
To prevent the relay assigned relay manager function 56 from energizing and de-
energizing continuously due to minor load swings, a hysteresis is configured in this
parameter. The value configured here is the amount the monitored power must drop
below the configured threshold in Parameter 141 before the corresponding relay
o
utput will de-energize.
Parameter 143
Gen.power monit.
delay lv1 000s
Power monitoring delay, level 1 0 to 650 s
For the control unit to recognize that the level 1 power monitoring threshold has
been exceed, the threshold value configured in Parameter 141 must be exceeded
wi
thout interruption for this period of time.
Parameter 144
Gen.power monit.
resp.val2 0000kW
Power monitoring threshold value, level 2 0 to 9,999 kW
If this threshold value has been exceeded for at least the delay time (Para-
meter 146), the relay assigned relay manager function 80 energizes.
Parameter 145
Gen.power monit.
hyst.lv2 000kW
Power monitoring hysteresis, level 2 0 to 999 kW
To prevent the relay assigned relay manager function 80 from energizing and de-
energizing continuously due to minor load swings, a hysteresis is configured in this
parameter. The value configured here is the amount the monitored power must drop
below the configured threshold in Parameter 144 before the corresponding relay
o
utput will de-energize.
Parameter 146
Gen.power monit.
delay lv2 000s
Power monitoring delay, level 2 0 to 650 s
For the control unit to recognize that the level 2 power monitoring threshold has
been exceedn, the threshold value configured in Parameter 144 must be exceeded
wi
thout interruption for this period of time.
