Manual 37365A GCP-30 Series Packages - Genset Control
Page 156/179 © Woodward
MUX
No.
Contents (words)
Unit Note
10/3 33
Configuration [T5]-[T8] Display in ...
#1#
°C °F bar/10 psi/10 % no unit
#1#: The analog input is not available or he
has been configured either as real power se
tpoint value or as mains (import/export)
real power value.
Note – On double /fourfold bits the follow-
ing is valid: If the indicated bit combination
is fulfilled (
high byte and low byte) ,the
message is active (otherwise inactive).
Analog input [T8]
Bit 15 = 0 0 0 1 1 1 0
Bit 14 = 0 1 1 0 0 1 0
Bit 13 = 0 0 1 0 1 0 1
Bit 12 = 0 1 0 1 0 0 1
Analog input [T7]
Bit 11 = 0 0 0 1 1 1 0
Bit 10 = 0 1 1 0 0 1 0
Bit 9 = 0 0 1 0 1 0 1
Bit 8 = 0 1 0 1 0 0 1
Analog input [T6]
Bit 7 = 0 0 0 1 1 1 0
Bit 6 = 0 1 1 0 0 1 0
Bit 5 = 0 0 1 0 1 0 1
Bit 4 = 0 1 0 1 0 0 1
Analog input [T5]
Bit 3 = 0 0 0 1 1 1 0
Bit 2 = 0 1 1 0 0 1 0
Bit 1 = 0 0 1 0 1 0 1
Bit 0 = 0 1 0 1 0 0 1
11/1 34
Mains voltage delta V
23
V × 10
UNTEXPO
11/2 35
Mains voltage delta V
31
V × 10
UNTEXPO
11/3 36
Mains voltage wye V
1N
V × 10
UNTEXPO
12/1 37
Mains voltage wye V
2N
V × 10
UNTEXPO
12/2 38
Mains voltage wye V
3
N
V × 10
UNTEXPO
12/3 39
Mains frequency out off V
N
12
/V
N
23
/V
N
31
Hz × 100
13/1 40
Mains current in L1 A × 10
INTEXPO
13/2 41
Mains reactive power var × 10
PNTEXPO
13/3 42
Mains power factor ϕ Example: FF9EH cos ϕ = c 0.98 (capacitive/lagging)
FF9DH cos ϕ = c 0.99 (capacitive/lagging)
0064H cos ϕ = 1.00
0063H cos ϕ = i 0.99 (inductive/leading)
0062H cos ϕ = i 0.98 (inductive/leading)
14/1 43
Exponents High Byte: PNTEXPO Mains power
Low Byte: UNTEXPO Mains voltage
14/2 44
Exponents High Byte: INTEXPO Mains current
Low Byte: USSEXPO Busbar voltage
14/3 45
Engine operating hours ( H.W.)
h × 2
16
Double word
15/1 46
Engine operating hours ( L.W.)
h
15/3 47
Hours until next maintenance h
15/3 48
Engine start number
