Woodway PATH - Page 124

124 03/2016 – UM-MT-EN-01
The running surface belt does not usually need adjustment. However, when the running
surface belt or corresponding parts are replaced, the belt tension must be checked.
Treadmill
Teeth to Teeth
Path
8.25”
Desmo/4Front/Mercury
8.5”
Pro Med
8.75”
Pro-XL Med
9.0”
ELG
16.5”
Running Belt
