Woodway PATH - Description of Display Elements; Quick Start (User-Defined Operation)

72 03/2016 – UM-MT-EN-01
The following values appear in the personal trainer display to allow the user to monitor
his progress:
 Speed profile
 Incline profile
 Time/ height
 METs
 Calories/distance
 Pace
 Heart rate
 Calories per hour
7.8.1 Description of Display Elements
The time is displayed in 00:00 format. In the user-defined mode, the time is counted up
from zero. In the program modes, the time is counted down.
The speed is displayed in 00.0 format. SPEED represents the user's current speed in
miles per hour (MPH), or it may be used to set the user's target speed. Valid speeds
range from 0.0 to the max. speed (varies depending on the model and applicable op-
tions).
The distance is displayed in 00.00 format. DISTANCE shows the accumulated user's
distance in miles. The distance is accumulated until the program is terminated or the
user presses the PAUSE button.
The calories are displayed in 0000 format. CALORIES shows the user's accumulated
burnt calories. They are calculated using the ACSM formula,
([Workout METs] * 3.5 * [User’s weight in kg.] / 200).
If no weight is entered, the calories are calculated based on a standard weight of 150
lbs. (70 kg).
The pace is displayed in 00:00 format. TIME represents the time required to run one
mile at the current speed.
METs are displayed in 00.0 format and are calculated using the ACSM formula,
(VO2 Max / 3.5), where the walking VO2 Max is (3.5 + [2.68 * speed in MPH] + [0.48 *
speed in MPH] * [% grade]) and the running VO2 Max is (3.5 + [5.36 * speed in MPH]
+ [0.24 * speed in MPH] * [% grade]).
The heart rate is displayed in 000 format. It represents the user's actual heart rate.
The INCLINE display is used to show the user's current incline or to set the incline. Valid
incline values start at 0% and increase in steps of 0.1% to the max. level of incline
(varies depending on the model and the associated options).
7.8.2 Quick Start (User-Defined Operation)
1. First, ensure that the treadmill is plugged into the power supply and that the power
switch (cutout in the side cover bottom right) is switched on.
2. Check that the emergency stop magnet is in place.
3. To turn the display press and hold the ON key until the LED and LCD displays are lit.
All functions can now be operated using the mentioned surrounding keys:
 Quick Start
 Manual Mode (with weight entry)
 Fitness programs
 Fitness tests
Note: All specified options are located on the far left of the display and can be selected
there directly.
Displayed
Information
TIME
SPEED
DISTANCE
CALORIES
PACE
METS
HEART RATE
INCLINE
