Woodway PATH - Desmo; Desmo H; Desmo HP; Elg

03/2016 – UM-MT-EN-01 23
3.3.2 Desmo / Desmo H / Desmo HP
Figure: Desmo
Desmo
 Running Surface: 22” W x 68” L (55 x 173 cm)
60 slats (replaceable), rubber on aluminum T-sections
Approx. 40 Shore A -- +/- 4 mm lateral tolerance
 Drive System: 114 ball bearings, 12 guide rollers
 Overall Dimensions:
38” W x 77” L x 63” H (97 x 196 x 160 cm)
 Weight: 445 lbs. (201 kg)
 Speed: 0-12.5 MPH (0-20 km/h) (0-15 MPH standard on HP)
 Incline: 0-15%
 LED Standard Display Board displays the parameters speed,
incline, distance, time, heart rate, calories burned, pace, and
METs
 Power Supply: 115 VAC 20 Amp (NEMA 5-20R outlet, 20 Amp
dedicated circuit required)
Options:
 Higher Speeds: up to 18 mph (29 km/h)
 Reverse: 0-5 mph (0-8 km/h)
 Steeper Incline: up to 25%
 Incline: (-3%)-(+22%)
 LCD Personal Trainer Display Board (standard on Desmo H)
 Power Supply Upgrade: 208/230 VAC 20 Amp
 Interface RS232 incl. Control Software
 Special Paint Finish
 Alternate Handrail Options
 Jump Plate
Additional options may be available.
Please contact your sales representative.
3.3.3 ELG
Figure: ELG
ELG
 Running Surface: 27” W x 96” L (70 x 244 cm)
87 slats (replaceable), rubber on aluminum T-sections
Approx. 40 Shore A -- +/- 4 mm lateral tolerance
 Drive System: 158 ball bearings, 16 guide rollers
 Overall Dimensions:
48” W x 102” L x 79” H (122 x 259 x 201 cm)
 Weight: 1634 lbs. (740 kg)
 Speed: 0-25 MPH (0-40 km/h)
 Incline: (-5%)-(+35%)
 LED Standard Display Board displays the parameters speed,
incline, distance, time, heart rate, calories burned, pace, and
METs
 Power Supply: 208/230 VAC 30 Amp (L6-30R outlet, 30 Amp
dedicated circuit required)
Options:
 Reverse: 0-5 mph (0-8 km/h)
 LCD Personal Trainer Board
 Interface RS232 incl. Control Software
 Special Paint Finish
 Single Handrail
 Gantry Suspension System
Additional options may be available.
Please contact your sales representative.
