3.5.2 Starting the update of the terminal firmware
1 Unplug the plug-in power supply and measuring
module (active multifunction box) from the inoLab
Level 3 terminal.
2 Download the installation program for the firmware
update, e.g. from the Internet.
3 Start the installation program for the firmware update.
The program creates an entry in the Windows start
bar (in the standard installation under Start /
Programme / Firmware Update inoLab Terminal V
x.x..)
4 Start the update program.
The Terminal Programming window opens and
displays instructions for the update.
5 Select the required language for the installation
program in the Language menu.
6 Change the COM interface displayed in the
V24Parameter menu if necessary.
7 Plug the AK T-PC serial cable into the "RS232/REC"
socket (19) on the terminal and connect with the
interface (COM 1 ... 4) of the PC selected in the
V24Parameter menu.
