Xerox 6204 Wide Format Solution Participant Guide
13
5 Loading & Cutting Roll Media
This section describes how to load roll media in the Xerox 6204
Wide Format Solution and cut the lead edge to ensure a good,
clean first copy or print from the new roll. Loading media is a basic
skill that must be performed whenever a roll of media runs out or
you wish to make a copy or print on a different size media than
what is loaded.
Objectives
When you complete this section you will be able to:
• Correctly load roll media in the media drawers.
• Trim the lead edge of the roll media using the cutter button.
Reading Activity
Read the following sections in the User Guide before loading and
cutting roll media.
2 Product Overview:
Loading Media/Roll Media
Cutting Roll Media
Resources Required
36” wide 20 pound bond roll paper (load in the upper media
drawer)
18” wide 20 pound bond roll paper (load in the lower media
drawer, if the machine is so equipped)
Procedure
The procedure for loading roll media is clearly presented in the
User Guide. The process involves just a few simple steps:
1. Open the front doors.
2. Unlatch and pull out the media drawer.
3. Remove the roll paper tube (shaft).
4. Remove the roll core or partially full roll from the tube.
5. Install a new roll of media on the roll core.
6. Install the roll and tube in the media drawer.
7. Cut the lead edge of the roll by pressing the cutter button.
8. Close the media drawer and the front doors
