5 Self-Diagnosis Mode RJ-901C/RJ-900C　 Maintenance Manual
5-14
NOTE
• For the following sensors, the sensor sensitivity is displayed in decimal number.
• P_EDGE sensor
• P_REAR sensor, Waste fluid box sensor
• For the ink ID sensor, installed ink cartridge type is displayed using the following ID numbers:
• 0: Cleaning liquid or shipping liquid
• 1: Dye-based ink (CMY)
• 2: Dye-based ink (K)
• 3: Undefined
• For the ink NOT sensor, the color of the ink whose cartridge is not inserted is displayed.
• For the ink end sensor, the color of the ink that has run out is displayed.
To Next Page
