2.3.2 Rear Section
Table 2-2 Part Names and Functions of Rear Section
No. Name Function
1 AC inlet For inserting the power cable plug.
2 Network interface
connector
Connector to connect a network interface cable.
3 USB cable connector Connector to connect USB cable.
4 Scroller receiver The scroller is set here when using roll media.
5 Media feed slot Insert media from here when feeding media.
6 Ink cartridge slot This holds the ink cartridge.
