RJ-901C/RJ-900C 　 Maintenance Manual 2 Product Overview
2-3
2.3 Part Names and Functions
Part names and functions are explained below.
NOTE
For the directions described in this document, refer to the following figure.
Rear
Upper
Lower
Right
Front
Left
