5 Self-Diagnosis Mode RJ-901C/RJ-900C　 Maintenance Manual
5-46
5.5.14 Software Counter Initialization Menu
This menu is used to initialize the software counters such as the waste ink counter.
NOTE
The counters are initialized before delivery. Do not initialize them during maintenance.
The software counters that can be initialized through this menu are as follows.
Pressing the [Enter] key in the operation panel performs the software counter initialization.
Pressing [Cancel] key cancels the initialization.
5.5.15 Feed Pitch Check Menu
In this menu, a function to confirm media feed amount for the one band is available. No adjustment can be
made on this menu.
To check the feed pitch, follow the steps below.
1. Set media as necessary.
2. Select "Adj: Send Pitch".
3. Select the feed pitch.
• Pattern 1: Prints at intervals of 360 (720) dpi. This resolution causes no gaps.
• Pattern 2: Prints at intervals of 1440 dpi. This causes a gap in one line out of four lines.
Table 5-11 Software Counters to be Initialized
Counter Initial
value
Waste ink amount counter
0
Ink consumption counter K
0
Ink consumption counter C
0
Ink consumption counter M
0
Ink consumption counter Y
0
Cumulative plot timer
0
Initial ink charge flag
1
Ink ID mask
0
Finish initialization
[Enter] key
Adjustment Menu
To Next Page
