5 Self-Diagnosis Mode RJ-901C/RJ-900C　 Maintenance Manual
5-38
5.5.8
CCW Adjustment
This menu is used to adjust the gap of the print positions caused by CR passes.
To adjust the gap of the print positions, at first print out a Uni-D printing and identify the difference of the
print positions. Then, enter the difference for the relevant parameters..
Adjustment items are shown in the tables below.
The actual procedure is as follows.
1. Set media as necessary.
2. After media is set, the machine prints out CCW adjustment check patterns.
Table 5-9 Uni-D Menu Items
Item Contents
CCW adjustment Low 1 CCW adjustment for low head height, PG 1 value, using 3-peak
waveform
CCW adjustment Low 2 CCW adjustment for low head height, PG 1 value, using 6-peak
waveform
CCW adjustment High 1 CCW adjustment for high head height, PG 2 value, using 3-peak
waveform
CCW adjustment High 2 CCW adjustment for high head height, PG 2 value, using 6-peak
waveform
表 5-10 Uni-D Adjustment Items
Item Contents
Gap1A-1B Uni-D (CCW) adjustment of nozzle row B to nozzle row A
Gap1A-2A Uni-D (CCW) adjustment of nozzle row C to nozzle row A
Gap1A-2B Uni-D (CCW) adjustment of nozzle row D to nozzle row A
Gap1A-3A Uni-D (CCW) adjustment of nozzle row E to nozzle row A
Gap1A-3B Uni-D (CCW) adjustment of nozzle row F to nozzle row A
Gap1A-4A Uni-D (CCW) adjustment of nozzle row G to nozzle row A
Gap1A-4B Uni-D (CCW) adjustment of nozzle row H to nozzle row A
To Next Page
