RJ-901C/RJ-900C 　 Maintenance Manual 7 Adjustment
7-23
7.5 PF Encoder Assembly Position Adjustment
This section describes the procedure to adjust the PF encoder assembly.
After replacing the PF encoder, adjust the PF encoder position with a jig.
7.5.1 Jigs and Tools
The jigs and tools required for PF encoder assembly position adjustment are as follows.
• Caliper
7.5.2 Adjustment Procedure
To adjust PF encoder, follow the steps below.
1. Align one end of a caliper with the grid roller.
No. Part name
1 Grid roller
2
Caliper


To Next Page
